Concept introduction of RJ45 connector with coil transformer

The goal of the connector’s impedance transformation is to match the resistance and reactance to achieve maximum transmission power for the load. Both the receiving and transmitting components at both ends of the network can provide efficiency and sensitivity. To realize this function, the use of RJ45 connector with coil is essential.

The basic concept of impedance transformation is that when the impedance between the front-stage circuit and the subsequent-stage circuit does not match, the transmission efficiency between the front-stage circuit as the signal source and the subsequent-stage circuit as the load is not high. Therefore, it is necessary to use a coiled RJ45 connection machine to complete the impedance transformation without loss or low loss.

The impedance conversion function can be achieved by using a transformer. The simplest way is to change the number of coil turns.

The RJ45 connector with coil can convert the discontinuous signal step transition into a smooth continuous transition through the impedance conversion function. This conversion is linear, so a good match can be achieved, providing better bandwidth.

Through the impedance conversion function, combined with filter circuits and coupling circuits, the operating frequency range of network components can be increased.

For details and type, please visit our website pages,

Posted on

Mini Cool Edge IO (MCIO) Connector Cable

This month we recommend you new products to give your engineers new knowledge and understanding in design and application.



Mini Cool Edge IO (MCIO) 85 Ohm X8 X16 vertical socket supports the building block architecture in system design and can connect PCBs with different functions.

Features

  • Provide flexibility for where/how signals are used in the system
  • Replaces PCB traces and PCB connector interfaces to provide higher performance channels
  • In-line, right-angle and lateral outlet cable options available for custom wiring
  • Complete product portfolio supports hybrid cable assemblies
  • Thin connector design saves space
  • MCIO 85 ohm supports PCIe5.0 (32 Gbps) and SAS4 (24 Gbps)
  • Multiple cable outlets for cabling functions
  • Board mount connector mounting type



The relative pictures are enclosed for kind viewing, drawing and quotation

Will be offered upon request.
